Montefiore Study May Help Establish Patient Criteria for Proton Therapy

N. Patrik Brodin, PhD
Published: Tuesday, May 21, 2019
montefiorePatrik Brodin, PhD
Patrik Brodin, PhD
Assistant professor
Radiation Oncology
Montefiore Einstein
Center for Cancer
Care and Albert
Einstein College of
Medicine, Bronx,
New York

Strategic Partnership
What is the most effective way to treat cancer? To some, the answer might seem straightforward, with the trifecta of chemotherapy, radiation, and surgery immediately coming to mind. Depending on the type of cancer, immunotherapies such as adoptive cell transfers, which strengthen a person’s own immune system, may also be a worthwhile strategy.

At Montefiore Einstein Center for Cancer Care and Albert Einstein College of Medicine’s Institute for Onco-Physics, we think about cancer treatments a little differently. Treatment is not just about destroying the cancer but also providing and helping to preserve the best quality of life (QoL) for our patients.

As one of the Centers for Medicare & Medicaid’s Oncology Care Models, we also wonder: What is the most cost-effective treatment option for our patients, and how can we most efficiently give our patients and their families the support they need?

In an effort to build more sophisticated protocols that keep QoL and cost questions at the forefront, we created a mathematical model to identify the optimal candidates for proton therapy, the most modern form of radiation therapy. Our focus: head and neck cancers.

Head and neck cancers account for approximately 3.0% of cancers in the United States, with most people receiving the diagnoses around age 60 years.1 With a rise in cases of oropharyngeal cancer linked to human papillomavirus (HPV) infections, we have been conducting research on new and better ways stratify patients and individualize cancer therapies.

Traditionally, we have used photon radiation therapy for our patients with head and neck cancers. However, proton therapy has emerged as an attractive option. This is due to proton therapy beam technology, which precisely destroys cancers with an unmatched ability to stop at precise locations within the body.

Protons also have significantly fewer adverse effects (AEs) and toxicities than most other cancer therapies, because of the protons’ unique ability to sculpt radiation doses according to the shapes and sizes of tumors. This is particularly important for head and neck cancers, which frequently are close to or impeding on vocal cords, air passageways, swallowing muscles, salivary glands, and the oral mucosa. The opportunity to preserve healthy tissue is considerable.

Analytical Methods for Comparing Therapies

To assess which of our patients would likely benefit the most from proton therapy, we conducted a modeling study of 33 patients with head and neck cancer previously treated with chemotherapy and definitive intensity-modulated radiation therapy using static fields or volumetric-modulated arc therapy. The average age of the participants was 61 years and their cancers were distributed as stage II (n = 8), III (n = 5), and IVa (n = 20).2

Figure 1. Proton Therapy Benefits Demonstrated in Study

Figure 1. Proton Therapy Benefits Demonstrated in Study Comparative proton therapy treatment plans were generated based on current clinical protocols, assuming similar treatment efficacy to that of standard photon therapy, which is supported by early clinical data.

Next, when reviewing each case, we estimated the impact of normal tissue complications from photon radiation therapy versus proton radiation therapy. Our goal was to have these results serve as a jumping-off point for creating a quantitative decision support system that can be used to identify optimal candidates for proton therapy.

In November 2018, we published our findings in the International Journal of Radiation Oncology.2 We found that on average, proton therapy can significantly spare the salivary glands, as well as the uninvolved oral cavity, jawbone, and thyroid glands. It is also particularly efficient in sparing the larynx and esophagus.

We then used QoL and cost effectiveness modeling. The efficacy of proton therapy translated into an average of 4.5 more months of life unimpeded by AEs compared with traditional photon radiation therapy. Specifically, we found that the quality-adjusted life-years (QALYs) lost as a result of complications was 1.52 with photon therapy versus 1.15 with proton therapy.2

AEs estimated to be significantly less prominent include swallowing difficulties, inflammation of the esophagus, and reduced saliva production.2 For people suffering from head and neck cancer and their families, the ability to avoid these types of complications makes an overwhelmingly important difference in QoL.

We found, however, that these types of results were not consistent for all people with head and neck cancers (Figure 1). Although some of our patients with head and neck cancer are likely to have these considerable benefits from proton therapy, others are likely to have very little or no benefit, despite all patients being treated with a similar approach according to current guidelines. (The QALYs spared with proton therapy ranged from 0.06 to 0.84.2)

Characteristics Associated With Benefit

Although data supporting the efficacy of proton therapy are robust for pediatric cancers, brain and base-of-skull tumors, and complex-shaped tumors near critical structures, the technology is also expensive and not always easily accessible.

Just as biomarkers have been developed to select chemotherapy, we wanted to identify factors that distinguish which patients would most benefit from this novel treatment and which would benefit from traditional photon radiation therapy.

These characteristics help determine who is most likely to benefit from proton therapy:
  • Age—younger patients who have longer life expectancy after treatment
  • Smoking status—non-smokers or those who have an insignificant smoking history
  • HPV status—patients with HPV p16- positive tumors, who have more promising prognoses and for whom reducing the AE profile is paramount
Regarding age, patients ≤65 years were spared 0.11 more QALYs with proton therapy, on average, compared with those >65 (P = .062). Participants with a smoking history of ≤10 packyears versus >10 pack-years were spared 0.10 more QALYs (P = .085). For HPV status, those with p16-negative tumors had an average increase of 0.16 fewer QALYs spared with proton therapy compared with patients with p16-positive tumors (P = .004). (Figure 2).2

Improving Quality of Life and Cost Effectiveness

According to the Agency for Healthcare Research and Quality (AHRQ), the direct medical costs for cancer in the United States approached billion in 2014.3 More recent cost estimates are closer to 0 billion.

Figure 2. QALY Impact in Head and Neck Cancer2

Figure 2. QALY Impact in Head and Neck Cancer2 The highest expense in cancer therapy involves the regrowth of cancer—large sums are required to prolong survival and maintain QoL. By increasing cure rates and improving patients’ QoL, we can increase cost-effectiveness.

It is important for healthcare providers not only to educate our patients and their families about each treatment’s ability to destroy cancers, but also to manage expectations about different treatments and what life may look like “post cancer.”

Proton therapy is one of the most modern therapies available, and its ability to minimize AEs such as trouble swallowing, reduced ability to eat, dental problems, and difficulty digesting food can’t be understated for some of our patients.

However, we need to do more, and conduct larger studies to pinpoint who these patients are and what they look like, as well as which individuals would benefit more from traditional or alternative therapies. This leads to better care for our patients and helps us prioritize valuable health system resources.

We are planning a larger retrospective study to validate these initial findings. Stay tuned for more.


  1. Cancer stat facts: oral cavity and pharynx cancer. National Cancer Institute website. Accessed May 9, 2019.
  2. Brodin NP, Kabarriti R, Pankuch M, et al. A quantitative clinical decision-support strategy identifying which patients with oropharyngeal head and neck cancer may benefit the most from proton radiation therapy [published online November 26, 2018]. Int J Radiat Oncol Biol Phys. 2018; pii: S0360-3016(18)34025-2. doi: 10.1016/j.ijrobp.2018.11.039.
  3. Center for Financing, Access and Cost Trends, Agency for Healthcare Research and Quality: Medical Expenditure Panel Survey, 2014. 9, 2019. Accessed May 9, 2019.
